We have evolved. Thanks to the combination of a high-efficiency IPM motor and a frequency converter (inverter), we have achieved a reduction in electricity consumption of up to 74%.
The 3 Pillars of the New NSP
Pillar 1: Extreme Energy Savings
- 74% savings: Compared to standard units, the new NSP with Inverter drastically reduces operating costs.
- Technological synergy: Combines a variable flow pump with the variable speed of an IPM (Internal Permanent Magnet) motor.
- Smart consumption: While the conventional NSP already saved 46%, the Inverter model raises performance to unprecedented levels.
Pillar 2: Comfort and Useful Life
- Office silence: Operates at only 54 dB(A) while maintaining a constant pressure of 6 MPa, a level comparable to an office environment.
- Low heat generation: The oil temperature increase is maintained at ambient temperature +5ºC or less.
- Durability: Less heat means a longer life for hydraulic fluid, rubbers, and seals.
Pillar 3: Intelligent Design and IoT
- Integrated Safety: Includes the STO (Safe Torque OFF) function as standard for a safe stop.
- Ready for Industry 4.0: Incorporates IoT monitoring functions for proactive control.
- Compact and Lightweight: Weighing only 39 kg (without options) and with optimized dimensions to fit into any machine tool.
Technical Specifications (Quick Table)
| Feature | Technical Detail |
| Input | 200V (200V ~ 240V) o 400V (380V ~ 480V) |
| Outlet flow | Upto 28 L/min (in vacuum) |
| Pressure Range | A2: 15 – 40 bar / A3: 35 – 60 bar / A4: 55 – 80 bar |
| Tank Capacity | 16 Liters |
| Recommended fluid | ISO VG32 mineral oil |
Model selection
Example Code: NSP-16E-S15V1A2-G-1590A * 16E: 16L Tank with Inverter Drive. * S: IPM Motor. * 15/22: Motor Power (1.5 kW or 2.2 kW equivalent). * G/HS/M: Options such as level protector, temperature/float switch, or magnetic separator.
